Airtac AirTAC 2KW Fluid Control Valve 2KW05010A
1. Direct-acting normally open 2/2-way solenoid valve with rapid response and high sensitivity;
2. Wide pressure range compatibility: Available in Ultra-high Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Versatile pilot-operated normally open 2/2-way solenoid valve featuring fast switching and high flow capacity;
4. Compact structure with space-saving design, lightweight construction, and tool-free maintenance;
5. Brass valve body with Class B thermal-rated coil. Standard FKM (Fluoroelastomer) seals ensure compatibility with multiple media. Custom seal materials available through technical consultation;
6. IP65-rated coil protection, available in direct lead-wire or DIN connector configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KW
AirTAC 2KW05010A Fluid Control Valve Technical Details
- Model: 2KW05010A
- Type: 2-position, 5-port direct-acting solenoid valve
- Port configuration: 5/2-way (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.1–1.0 MPa
- Maximum flow rate: 850 L/min (Cv=1.3)
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Response time: ≤25ms (excitation), ≤35ms (reset)
- Seal material: Heat-resistant NBR (Nitrile) - compatible with air, water, and light oils
- Ambient temperature range: -5℃ to 80℃ (with 0.5% lubricating oil)
- Protection class: IP67 (dustproof and waterproof)
- Electrical connection: DIN43650 Form A with LED indicator
- Weight: 0.68 kg (including coil)
- Dimensions: 58mm(W) × 52mm(H) × 127mm(L)
High-flow proportional control valve featuring zero-pressure differential operation capability. The anodized aluminum body with brass core components ensures durability in humid environments. Includes manual override and surge suppression circuitry. Requires ISO 8573-1 class 3 compressed air (max 50mg/m³ oil content).
- Automated assembly line clamping systems
- Plastic injection molding machine ejectors
- Beverage filling station pneumatic actuators
- Semiconductor wafer handling robotics
- Hydraulic system pilot stage control
Installation guidelines:
Mount horizontally with ports downward to prevent debris accumulation.
Use vibration-damping brackets if ambient vibration exceeds 5G.
Perform lubrication every 2,000 operating hours using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | 2KW05010A |
| Port Size | PT3/8 |
| Flow Aperture | <5mm> |
| Coil Voltage | AC220V |
