Airtac Airtac DS1J Electronic Sensor DS1J030
2. Its architecture comprises four core components: thermal sensing probe, signal processing unit, LCD interface module, and low-power consumption circuitry with stable power supply integration.
3. The thermal sensing probe serves as the critical sensing element, employing precision-engineered rapid-response thermistor arrays that directly govern measurement accuracy and thermal tracking responsiveness.
AirTAC DS1J Series Electronic Sensor DS1J030 Technical Specifications
- Model: DS1J030
- Type: Inductive proximity sensor (non-contact)
- Sensing distance: 3mm ±10%
- Output configuration: NPN/PNP selectable (NO+NC)
- Supply voltage: 12-24VDC ±10% (ripple ≤10%)
- Current consumption: ≤15mA
- Response frequency: 1kHz max
- Hysteresis: ≤15% of sensing distance
- Output current: ≤200mA
- Protection rating: IP67 (IEC60529)
- Housing material: Nickel-plated brass
- Operating temperature: -25℃ to +70℃
- Storage temperature: -40℃ to +85℃
- Vibration resistance: 10-55Hz @ 1.5mm amplitude
- Shock resistance: 1000m/s² (3 times each axis)
- Cable length: 2m standard (PUR jacket)
- Weight: 82g ±3% (with cable)
- Dimensions: 30mm(W) × 15mm(D) × 40mm(H)
- Certifications: CE, RoHS, REACH compliant
High-precision industrial-grade inductive sensor featuring dual NPN/PNP programmable output modes. The DS1J030's triple-layer epoxy encapsulation provides exceptional resistance to cutting fluids and metal particles. Its embedded temperature compensation circuit maintains stable detection performance across extreme temperature variations.
- Position verification in CNC turret tool changers
- Sheet metal counting in stamping presses
- End-of-stroke detection for pneumatic cylinders
- Pallet presence monitoring in automated warehouses
- Rotor position sensing in brushless DC motors
Installation guidelines:
Maintain 2× sensor diameter clearance from adjacent metal surfaces.
For optimal performance in high-vibration environments, use M4 anti-loosening nuts
and apply thread-locking compound. Avoid mounting near high-frequency inverters (>10kHz).
| Property | Property Value |
|---|---|
| sku | DS1J030 |
