Airtac Airtac DS1J Electronic Sensor DS1JP020
2. Its architecture comprises four core components: thermal sensing probe, signal processing unit, LCD interface module, and low-power consumption circuitry with stable power supply integration.
3. The thermal sensing probe serves as the critical sensing element, employing precision-engineered rapid-response thermistor arrays that directly govern measurement accuracy and thermal tracking responsiveness.
AirTAC DS1J Electronic Sensor DS1JP020 Technical Details
- Model: DS1JP020
- Sensor type: Inductive proximity sensor
- Detection principle: Non-contact electromagnetic field
- Detection distance: 2mm ±10%
- Output configuration: NPN normally open (NO)
- Supply voltage: DC 10-30V (±10% ripple)
- Current consumption: ≤15mA
- Response frequency: 500Hz
- Hysteresis: ≤15% of detection distance
- Protection rating: IP67 (IEC standard)
- Housing material: Nickel-plated brass
- Operating temperature: -25℃ to +70℃
- Connection type: 2m PVC cable (M8 connector optional)
- Weight: 98g ±3g
- Dimensions: 34mm(W) × 34mm(H) × 18mm(D)
High-precision industrial sensor with temperature compensation circuitry, featuring reverse polarity protection and short-circuit prevention. The brass housing provides EMI/RFI shielding and mechanical durability in high-vibration environments. Requires metallic targets (iron/steel ≥3mm thickness for optimal performance).
- Position verification in pneumatic cylinder systems
- Sheet metal counting in stamping machines
- Tool presence detection in CNC turrets
- Conveyor belt object tracking
- Robotic arm end effector alignment
Installation guidelines:
Maintain 1.5x detection distance clearance from adjacent metal surfaces.
For cylindrical targets, diameter should exceed 3× sensor face diameter.
Clean sensing face weekly using isopropyl alcohol in dusty environments.
| Property | Property Value |
|---|---|
| sku | DS1JP020 |
