Airtac AIRTAC SC125-160 Standard Cylinder SC125X250
$174.44
Regular price
$181.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SC125X250
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SC125~160 Standard Cylinder Series (ISO 6430)
1. Compliant with ISO 6430 international cylinder standard;
2. Features specially profiled bidirectional piston sealing with integrated oil reservoir for compact dimensions and extended lubrication;
3. Tie-rod construction with precision fasteners connecting end covers to aluminum alloy tube, ensuring enhanced structural integrity;
4. Compact axial length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Adjustable pneumatic cushioning with precise stroke control;
6. Flexible sensor integration via optional magnet pistons and embedded mounting slots for proximity sensors;
7. Comprehensive range of mounting accessories and configuration options for diverse industrial applications;
8. High-temperature resistant seals enable operational range of 0-150°C.
Category: Piston Cylinders | Brand: AirTAC | Series: SC125~160
Installation Guidelines:
1. Allow 15mm minimum clearance around cylinder body for heat dissipation
2. Use anti-vibration pads when mounting on moving platforms
3. Lubricate through air supply (ISO VG32 turbine oil recommended)
4. Maximum side load capacity: 350N at rod end
5. Cycle rate not to exceed 80% duty cycle at maximum stroke
1. Compliant with ISO 6430 international cylinder standard;
2. Features specially profiled bidirectional piston sealing with integrated oil reservoir for compact dimensions and extended lubrication;
3. Tie-rod construction with precision fasteners connecting end covers to aluminum alloy tube, ensuring enhanced structural integrity;
4. Compact axial length compared to ISO 15552 standard cylinders at equivalent bore sizes;
5. Adjustable pneumatic cushioning with precise stroke control;
6. Flexible sensor integration via optional magnet pistons and embedded mounting slots for proximity sensors;
7. Comprehensive range of mounting accessories and configuration options for diverse industrial applications;
8. High-temperature resistant seals enable operational range of 0-150°C.
Category: Piston Cylinders | Brand: AirTAC | Series: SC125~160
AirTAC SC125~160 Series Standard Cylinder SC125X250 Technical Specifications
- Model Code: SC125X250
- Bore Size: 125mm (4.92")
- Stroke: 250mm (9.84")
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning Type: Adjustable air cushion (both ends)
- Mounting Style: Basic type (standard flange options available)
- Port Size: G1/2 (ISO standard tapered thread)
- Piston Rod Thread: M36×1.5 (external)
- Cylinder Tube Material: Aluminum alloy hard anodized
- Seal Material: NBR + PU combination
- Piston Rod Material: Chrome-plated carbon steel
- Weight: 12.8 kg (28.2 lbs)
- Dimensions (L×W×H):
- Extended Length: 617mm
- Retracted Length: 367mm
- Body Width: 155mm
- Mounting Height: 125mm
- Max Theoretical Force (@0.63MPa):
- Thrust: 7,733N
- Tension: 6,748N
High-torque industrial cylinder with double-acting operation, featuring wear-resistant composite seals and precision honed inner tube. The triple sealing structure ensures reliable performance in high-cycle applications. Requires ISO 8573-1:2010 [3:4:3] class compressed air with 20-50μm filtration.
Typical Industrial Applications:
- Metal stamping press ejection systems
- Automotive welding fixture positioning
- Injection molding machine core pulling
- Heavy-duty conveyor gate control
- Construction machinery actuation
Installation Guidelines:1. Allow 15mm minimum clearance around cylinder body for heat dissipation
2. Use anti-vibration pads when mounting on moving platforms
3. Lubricate through air supply (ISO VG32 turbine oil recommended)
4. Maximum side load capacity: 350N at rod end
5. Cycle rate not to exceed 80% duty cycle at maximum stroke
Service Life:
Typical 5,000km travel distance before seal replacement under standard conditions (clean air, 1m/s average speed, ambient temperature)
| Property | Property Value |
|---|---|
| sku | SC125X250 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 125mm |
| Stroke | <250MM> → <250mm> |
