Airtac AQK Dowel Pin Cylinder AQK50SAAA-148X290
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-148X290 Pin Cylinder Specifications
- Model: AQK50SAAA-148X290
- Type: Double-acting pin-type cylinder
- Bore size: Ø50 mm
- Stroke: 290 mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Port size: G1/4 (ISO standard)
- Piston rod thread: M16×1.5
- Ambient temperature: -20℃ to 80℃
- Tube material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seal material: NBR (nitrile rubber)
- Weight: 3.8 kg ±2%
- Dimensions: 548mm(L) × 60mm(W) × 60mm(H)
- Mounting type: Front flange (ISO 15552 standard)
- Protection rating: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (recommended relubrication cycle: 2000 km)
High-rigidity pin cylinder designed for precision positioning in heavy-duty applications. Features dual chrome-plated guide rods for enhanced lateral load capacity (max 450N at full extension). The hexagonal body design allows direct sensor mounting and provides anti-rotation stability. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 cleanliness.
- Automated welding fixture positioning systems
- Die-casting machine core-pulling mechanisms
- Automotive assembly line clamping devices
- Heavy-duty material handling equipment
- Precision glass cutting machinery
Installation note:
Maintain 0.05mm/m alignment tolerance during mounting. Use M8×1.25 mounting screws (grade 8.8 or higher)
with 25-30 N·m torque. For vertical installations, install air exhaust silencers to prevent condensation ingress.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-148X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
