Airtac AQK Dowel Pin Cylinder AQK50SAAA-158X290
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-158X290 Rodless Cylinder Specifications
- Model Code Breakdown:
- AQK: Rodless cylinder series
- 50: Bore size 50mm
- S: Double-acting type
- AAA: Standard configuration with auto switch groove
- 158: Stroke length 158mm
- 290: Extended model code for sealing/coating variant
- Bore Diameter: Ø50mm (±0.1mm manufacturing tolerance)
- Stroke: 158mm (adjustable stroke stopper optional)
- Operating Pressure: 0.05-1.0 MPa (7-145 psi)
- Piston Speed: 50-700 mm/s (lubricated operation)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port Size: G1/8 (NPT1/4 optional)
- Seal Material: HNBR rubber (high nitrile for oil resistance)
- Piston Rod: Hard chrome-plated SUS304 stainless steel
- Temperature Range: -20℃ to 80℃ (dry air required below 0℃)
- Protection Class: IP54 (standard wiper seal)
- Weight: 3.85 kg (including mounting brackets)
- Dimensions:
- Body Length: 290mm (stroke excluded)
- Total Length: 290 + 158 = 448mm
- Width: 68mm (including guide rail)
- Height: 60mm (mounting surface to top)
High-precision rodless cylinder with integrated linear guide system, featuring zero air leakage design through advanced sliding seals. The dual-slot structure ensures stable load handling with maximum moment resistance of 58N·m. Compatible with both magnetic and mechanical position sensors.
- PCB handling robots in electronics manufacturing
- Automotive door panel pressing mechanisms
- Pharmaceutical blister packaging systems
- Solar panel lamination line positioners
- Glass cutting machine sliding units
Maintenance Protocol:
Lubricate every 3 months with ISO VG32 turbine oil (1-2 drops per port).
Avoid lateral force exceeding 15% of maximum thrust. Alignment tolerance: ≤0.2mm/m.
- Horizontal: Use dual support brackets (M8×1.25 bolts)
- Vertical: Requires counterbalance valve (not included)
- Angled: Max 15° deviation from axis with lubrication upgrade
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-158X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
