Airtac AQK Dowel Pin Cylinder AQK50SAAA-177X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Series Pin Cylinder AQK50SAAA-177X340 Technical Specifications
- Model Code: AQK50SAAA-177X340
- Type: Double-acting pin cylinder with auto-rotation prevention
- Bore size: Ø50 mm (ISO 6432 standard)
- Stroke length: 340 mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s (lubricated condition)
- Mounting style: Front flange with through-hole (177mm center distance)
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Ambient temperature: -20℃ to 80℃
- Piston material: Hard-anodized aluminum alloy
- Rod material: Stainless steel SUS304
- Seal type: NBR + PU combination seals
- Protection class: IP54 (standard) / IP67 (optional)
- Cushioning: Adjustable elastic buffer + shock absorber pad
- Weight: 3.8 kg (excluding accessories)
- Dimensions: 548mm(L) × 82mm(W) × 82mm(H) (fully extended)
High-precision industrial cylinder featuring anti-rotation pin guidance for strict linear motion requirements. The 5-stage surface treatment process ensures corrosion resistance in humid environments. Integrated buffer adjustment screws allow fine-tuning of end-position damping. Requires ISO 8573-1:2010 Class 3 compressed air.
- Precision alignment in semiconductor wafer handling robots
- Vertical lifting mechanisms for CNC tool changers
- Clamping fixtures for automotive welding lines
- Packaging machine product positioning systems
- Pharmaceutical blister packaging sealing units
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3mm minimum parallel alignment tolerance between rod and load.
Use flexible couplings for side load applications.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-177X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
