Airtac AQK Dowel Pin Cylinder AQK50SAAA-178X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-178X340 Rod Style Cylinder Specifications
- Model: AQK50SAAA-178X340
- Type: Double-acting rod cylinder with magnetic piston
- Bore size: Ø50 mm
- Stroke: 340 mm
- Operating pressure: 0.05–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting: Standard foot mounting (ISO 15552 compliant)
- Port size: G1/8 (Rc1/8 optional)
- Piston rod thread: M16×1.5
- Material:
- Cylinder tube: Aluminum alloy hard anodized
- End caps: Aluminum alloy
- Piston rod: Stainless steel (SUS304)
- Seals: NBR/PU compound seals
- Weight: 5.8 kg (±2%)
- Dimensions:
- Length: 678 mm (full extension)
- Width: 82 mm (mounting base)
- Height: 65 mm (body diameter)
- Position detection: Built-in magnet for sensor mounting
- Protection rating: IP65 (rod seal)
Heavy-duty precision cylinder engineered for high lateral load applications. Features wear-resistant chromium-plated rod guide and dual anti-rotation pins for enhanced stability. The low-friction design achieves ≤0.15 MPa starting pressure, with 98% volumetric efficiency. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automated welding fixture positioning
- Palletizing robot end-effector drives
- Die-casting machine core-pull mechanisms
- Textile machinery tension control systems
- Automotive assembly line clamping units
Installation note:
Maintain ≤0.1mm/m alignment tolerance during mounting. Apply Molykote 111 lubricant
to rod threads during maintenance. Avoid side loads exceeding 180N at full extension.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-178X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
