Airtac AQK Dowel Pin Cylinder AQK50SAAA-179X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Pin Cylinder AQK50SAAA-179X340 Technical Specifications
- Model Code: AQK50SAAA-179X340 (ISO 6432 compliant)
- Bore Size: Ø50 mm (±0.2mm manufacturing tolerance)
- Stroke Length: 340 mm (adjustable with stroke adjustment collar)
- Rod Thread: M16×1.5 (external thread, 45HRC hardened)
- Operating Pressure: 0.05-1.0 MPa (1.5MPa burst pressure rating)
- Cushioning Type: Air cushion adjustable via needle valves (both ends)
- Piston Speed: 50-800 mm/s (lubricated condition)
- Ambient Temperature: -20℃ to 80℃ (NBR seals)/-10℃ to 70℃ (FKM seals)
- Mounting Style: SA-type foot mounting (4×M8 mounting holes)
- Port Size: G3/8 (BSPP thread, dual ports)
- Rod End: Female threaded (M16×1.5) with anti-rotation hex
- Body Material: Aluminum alloy (anodized surface)
- Weight: 4.8 kg (±3% production variance)
- Dimensions:
- Length: 179mm (base dimension) + 340mm stroke
- Width: 82mm (mounting foot span)
- Height: 62mm (cylinder body diameter)
High-rigidity pin cylinder designed for precision linear motion in heavy-duty applications. Features dual chrome-plated piston rods (ø16mm) with integrated wear-resistant guides, providing exceptional moment resistance (35N·m max lateral moment). Includes built-in magnet for position sensing compatibility. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Automated welding fixture positioning systems
- Press machine ejection mechanisms
- Plastic injection molding machine core pulls
- Palletizing robot end-effector actuators
- CNC machine tool clamping units
Maintenance Protocol:
Lubricate with ISO VG32 hydraulic oil monthly in dry operation.
Avoid angular misalignment exceeding ±2° during installation.
Use backup nuts on rod ends when handling >100kg suspended loads.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-179X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
