Airtac AQK Dowel Pin Cylinder AQK50SAAA-197X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-197X340 Rodless Cylinder Specifications
- Model: AQK50SAAA-197X340
- Bore size: 50mm (1.97")
- Stroke length: 340mm (13.39")
- Operating pressure: 0.05–0.9 MPa (7–130 psi)
- Action type: Double-acting
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: Rc1/4 (NPT1/4 optional)
- Piston rod thread: M16×1.5
- Temperature range: -20℃ to 80℃ (-4℉ to 176℉)
- Tube material: Hard anodized aluminum alloy
- Seal material: NBR (Nitrile) with wear-resistant ring
- Mounting type: Standard ISO 15552 front flange (MF1)
- Weight: 5.8kg (12.8lbs)
- Dimensions: 600mm(L) × 80mm(W) × 80mm(H)
- ISO certification: 6431, VDMA 24562
Precision-engineered rodless cylinder with integrated magnetic sensor slot (T-slot design), featuring smooth linear motion and high positioning accuracy (±0.5mm repeatability). The aluminum construction with chrome-plated piston rod ensures corrosion resistance in humid environments. Includes built-in auto-switch mounting grooves for sensor installation.
- CNC machine tool clamping systems
- Automated conveyor sorting mechanisms
- Robotic welding positioners
- Lithium battery production line handling
- Semiconductor wafer transfer systems
Maintenance note:
Lubricate with ISO VG32 hydraulic oil monthly in continuous operation.
Avoid side load exceeding 30N·m. For vertical mounting, use auxiliary
guide mechanisms for stroke lengths >200mm.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-197X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
