Airtac AQK Dowel Pin Cylinder AQK50SAAA-198X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-198X340 Rodless Cylinder Specifications
- Model: AQK50SAAA-198X340
- Type: Double-acting rodless cylinder (slot-free magnetic coupling)
- Bore size: 50mm
- Stroke: 340mm
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Port size: PT1/4 (G1/4 optional)
- Piston seal material: NBR + PU hybrid
- Mounting style: Standard ISO 15552 mounting grooves
- Position detection: Pre-drilled slots for magnetic sensors
- Weight: 5.8kg ±2% (without accessories)
- Dimensions: 598mm(L) × 50mm(W) × 82mm(H)
- Rodless carriage: 198mm center-to-center mounting hole spacing
- Repeat accuracy: ±0.5mm
- IP rating: IP54 (standard), IP67 optional
High-precision rodless cylinder featuring magnetic coupling technology for smooth linear motion. The slot-free design prevents contamination buildup, making it ideal for cleanroom applications. Its anodized aluminum construction provides corrosion resistance, while the dual adjustable cushions enable precise end-position control. Requires 5μm filtered air and ISO VG32 hydraulic oil mist lubrication (0.3–0.5cc/min).
- High-speed pick-and-place systems in electronics assembly
- Precision material transfer in semiconductor manufacturing
- Automated packaging line conveyor synchronization
- Pressurized chamber door mechanisms
- Glass panel handling robots
Installation guidelines:
Maintain parallel alignment within 0.1mm/m tolerance during mounting.
Use only brass or stainless steel fittings – aluminum adapters may cause galvanic corrosion.
Perform initial lubrication cycle (50 full strokes at 0.3MPa) before load operation.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-198X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
