Airtac AQK Dowel Pin Cylinder AQK50SAAA-199X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-199X340 Rodless Cylinder Specifications
- Model: AQK50SAAA-199X340
- Type: Double-acting rodless cylinder (magnetic coupling)
- Bore size: Ø50 mm
- Stroke: 199 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air cushion at both ends
- Port size: 1/4" NPT (G1/8 optional)
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR + PU combination
- Tube material: Aluminum alloy (hard anodized)
- Slider material: High-strength aluminum with wear-resistant coating
- Weight: 3.8 kg (without accessories)
- Dimensions: 340mm(L) × 76mm(W) × 76mm(H)
- Mounting: Standard ISO 15552 mounting slots
- Position detection: Compatible with magnetic sensors (SM/SD series)
High-precision rodless cylinder designed for space-constrained linear motion applications. Features zero-leakage magnetic coupling technology and dual-guide rail structure for enhanced lateral load capacity. The stainless steel band seal ensures long-term dust resistance (IP54 standard).
- Plastic injection molding machine ejectors
- Automated palletizing systems
- Precision glass panel handling
- Semiconductor wafer transfer mechanisms
- Automotive welding fixture positioning
Installation note:
Requires precise alignment (≤0.2mm/m parallelism tolerance) with guided structures.
Use AirTAC recommended lubricator (VG32 grade oil mist) for initial commissioning.
Avoid lateral forces exceeding 200N during operation.
- Speed controller: ASC-2000 series
- Mounting bracket: AMB-50S
- Magnetic sensor: SM-15P
- Coupling kit: CK-50M (for tandem configurations)
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-199X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
