Airtac AQK Dowel Pin Cylinder AQK50SAAA-248X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Series Rod-Type Cylinder AQK50SAAA-248X340 Technical Details
- Model Code: AQK50SAAA-248X340
- Type: Double-acting rod cylinder with square base
- Bore size: Ø50 mm (ISO 6432 standard)
- Stroke length: 340 mm (adjustable within ±1mm tolerance)
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Cushion type: Adjustable air cushion at both ends
- Mounting style: Front flange with through holes (NF series pattern)
- Port size: M5x0.8 (G1/8 adaptor optional)
- Piston rod thread: M16x1.5 (external)
- Temperature range: -20℃ to 80℃ (non-freezing conditions)
- Main materials:
- Barrel: Aluminum alloy hard anodized
- Piston rod: Chrome-plated steel (Cr-Mo)
- Seals: NBR + special wear-resistant ring
- Weight: 3.8 kg (±2%)
- Dimensions:
- Body length: 248 mm (excluding rod)
- Full extended length: 588 mm (248+340)
- Square base: 80x80 mm
- Rod diameter: Ø20 mm
High-rigidity precision cylinder with integrated guide mechanism, designed for applications requiring exceptional lateral load capacity (up to 200N·m). Features anti-rotation design with four precision-ground guide rods and dual preloaded linear bearings. Optional magnetic piston version (suffix /M) available for position feedback.
- Vertical lifting systems in automotive assembly lines
- Precision alignment in semiconductor wafer handling
- Heavy-duty clamping fixtures for CNC machining centers
- Material transfer arms in cold storage facilities
- High-cycle packaging machine pusher mechanisms
Installation requirements:
Maintain perpendicularity within 0.2mm/m during mounting. Lubricate with ISO VG32 turbine oil
during initial setup. For vertical mounting, install air exhaust mist separator to prevent oil drain.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-248X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
