Airtac AQK Dowel Pin Cylinder AQK50SAAA-249X340
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA-249X340 Rodless Cylinder Specifications
- Model: AQK50SAAA-249X340
- Type: ISO15552-compliant rodless cylinder (double-acting)
- Bore size: Ø50 mm
- Stroke length: 340 mm (customizable up to 2,000 mm)
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (front/rear)
- Port size: G1/2 (NPT1/2 optional)
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: Heat-resistant NBR with wear ring
- Rod material: Hard-anodized aluminum alloy
- Mounting type: Standard AF (flange) + AAA accessory code (custom)
- Weight: 5.8 kg (including mounting hardware)
- Dimensions:
- Length: 249 mm (base length) + 340 mm (stroke)
- Width: 78 mm (profile width)
- Height: 82 mm (including carriage)
- Position detection: Slot for mounting magnetic sensors (SM/SMC series)
- Protection rating: IP54 (standard), IP67 with optional wiper seals
High-precision rodless cylinder with integrated linear guide rails, designed for heavy payload applications requiring smooth motion and minimal deflection. Features corrosion-resistant construction with dual stainless steel bands and self-lubricating bearings. The 50mm bore model delivers up to 1,570N thrust force at 0.6MPa.
- Automated palletizing systems
- CNC machine tool changers
- Electronics PCB handling robots
- Automotive welding jig positioning
- Pharmaceutical blister packaging lines
Installation guidelines:
Requires 0.5Nm torque for sensor mounting screws. Lubricate through air supply (ISO VG32).
Avoid side load exceeding 300N. For vertical mounting, use mechanical brake option (add suffix /B).
| Property | Property Value |
|---|---|
| sku | AQK50SAAA-249X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
