Airtac AQK Dowel Pin Cylinder AQK50SAAA2-147X310
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Series Rod Cylinder AQK50SAAA2-147X310 Specifications
- Model: AQK50SAAA2-147X310
- Type: Double-acting rod cylinder with magnetic piston
- Bore size: Ø50 mm
- Stroke: 310 mm (customizable 10-2000mm)
- Rod diameter: Ø20 mm
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: G1/2 (M16x1.5 optional)
- Mounting type: Front flange with precision guide pins (ISO 15552 standard)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR + PU hybrid seals
- Weight: 5.8 kg (with standard accessories)
- Dimensions:
- Total length (L): 147 + 310 = 457 mm
- Body width (W): 70 mm
- Height with pins (H): 110 mm
- Mounting hole spacing: 110x80 mm
- ISO compatibility: 15552 (formerly ISO 6431)
- Protection rating: IP65 (standard), IP67 optional
High-rigidity rod cylinder designed for precision linear motion systems requiring anti-rotation stability. Features dual 10mm hardened steel guide pins for enhanced lateral load capacity (max 300N·m). The reinforced piston design achieves 98% mechanical efficiency at 0.5MPa. Includes built-in magnet for position sensing compatibility with all major brand sensors.
- Automated welding fixture positioning systems
- Die-casting machine core-pulling mechanisms
- Glass handling robotic end effectors
- CNC rotary table clamping units
- Lithium battery stacking production lines
Installation protocol:
Use torque-controlled tightening (35-40N·m for M10 mounting bolts).
Requires minimum 5μm filtered air with ISO 8573-1:2010 Class 3.4.2 quality.
Lubricate via port with ISO VG32 pneumatic oil during initial commissioning.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-147X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
