Airtac AQK Dowel Pin Cylinder AQK50SAAA2-148X310
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-148X310 Rodless Cylinder Specifications
- Model: AQK50SAAA2-148X310
- Type: ISO15552 compliant rodless cylinder
- Bore size: 50mm (1.97")
- Stroke length: 310mm (12.2")
- Operating pressure: 0.05–1.0 MPa (7-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Cushioning: Adjustable air cushion (both ends)
- Mounting type: Standard foot + front flange (A2 suffix)
- Port size: M5x0.8 (G1/8 optional)
- Piston rod thread: M14x1.5
- Material: Aluminum barrel, hardened steel guide rail
- Seal material: NBR + PU combination
- Protection rating: IP54 (standard), IP67 optional
- Weight: 3.8kg (8.38 lbs)
- Dimensions: 548mm(L) × 60mm(W) × 50mm(H)
High-precision rodless cylinder with integrated linear guide, designed for heavy-duty applications requiring exceptional moment resistance. Features dual sealing system with dust wiper and maintenance-free lubrication. The 148X suffix indicates 148mm between mounting holes for customized fixture integration.
- Palletizing robot vertical lift mechanisms
- CNC machine tool automatic door systems
- Automotive welding fixture positioning
- Electronics assembly line transfer units
- Packaging machine cross-beam drives
Installation note:
Requires precise alignment of guide rail mounting surface (flatness ≤0.1mm/m).
Use anti-vibration washers when operating above 2m/s piston speed.
Lubricate through air supply (ISO VG32 recommended).
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-148X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
