Airtac AQK Dowel Pin Cylinder AQK50SAAA2-149X310
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-149X310 Rodless Cylinder Specifications
- Model Decoding: AQK50SAAA2-149X310
- AQK: Rodless cylinder series
- 50: Bore size (50mm)
- S: Double-acting type
- AAA: Auto switch type (3-wire NPN/PNP)
- 2: Front flange mounting
- 149: Stroke length (149mm)
- X310: Extended stroke variant code
- Bore diameter: 50mm (±0.13mm tolerance)
- Stroke: 149mm (adjustable cushioning)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max thrust: 157N at 0.5MPa (push/pull)
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Material:
- Cylinder tube: Hard anodized aluminum
- Piston rod: Chrome-plated steel
- Seals: HNBR (Hydrogenated Nitrile)
- Weight: 3.2kg (with mounting brackets)
- Dimensions:
- Length: 310mm (stroke + end caps)
- Width: 72mm (including guide rails)
- Height: 50mm (bore diameter equivalent)
- Position detection: Built-in magnetic sensor (2m cable)
- ISO Standard: 15552 compliant
- Protection class: IP54 (dust/water resistant)
Precision-guided rodless cylinder with T-slot design for multi-axis mounting. Features dual adjustable cushioning with polyurethane shock absorbers and wear-resistant guide bearings. Integrated sensor groove allows multiple position feedback device installation. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Cartesian robot XYZ-axis drives
- CNC machine tool clamping systems
- Automated conveyor sorting arms
- Glass panel vacuum lifting devices
- Pharmaceutical blister packaging
Mounting advice:
Align guide rails within 0.05mm/m parallel tolerance. Use M6x12mm SHCS
(socket head cap screws) with 4.4Nm torque for flange mounting. Lubricate
monthly with AirTAC PAG-32 grease in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-149X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
