Airtac AQK Dowel Pin Cylinder AQK50SAAA2-157X310
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK Pin Cylinder AQK50SAAA2-157X310 Technical Specifications
- Model Code Breakdown:
AQK50-S-AAA-2-157X310
• AQK: Pin cylinder series
• 50: Bore size (50mm)
• S: Double-acting type
• AAA: Adjustable cushioning (both ends)
• 2: Mounting style (front flange with rod end threads)
• 157: Stroke length (157mm)
• 310: Rod end configuration (external thread M20x1.5) - Bore Diameter: 50mm (±0.1mm manufacturing tolerance)
- Stroke: 157mm (customizable up to 300mm)
- Operating Pressure: 0.05-1.0 MPa (7-145 PSI)
- Medium Temperature: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning: 3-stage adjustable (5mm/10mm/15mm buffer length)
- Port Size: G3/8 (ISO standard) with NPT adaptor option
- Piston Rod Thread: M20×1.5 (8.4mm rod diameter)
- Mounting: ISO 15552 front flange (4×M8 mounting holes)
- Material:
- Barrel: Aluminum alloy AL6061-T6 (hard anodized)
- Piston Rod: Chrome-plated SCM435 steel
- Seals: NBR+PU hybrid (oil-resistant up to ISO VG32)
- Weight: 3.85kg (without accessories)
- Dimensions (L×W×H):
- Total Length: 157(stroke)+220(body)=377mm
- Flange Width: 88mm (mounting center distance 70mm)
- Height: 62mm (from cylinder centerline to base)
- Cycle Life: 5,000km travel distance (at 0.5MPa, 20℃)
High-precision industrial cylinder featuring progressive cushioning control and reinforced rod bearing structure. The aluminum barrel with internal honing process achieves ≤0.05mm roundness tolerance. Integrated magnet slot allows for sensor mounting (SM/SD series magnetic switches compatible). Requires 40μm filtered air with lubrication (ISO VG32 recommended).
- Stamping machine die positioning systems
- Automated pallet clamping in CNC machining centers
- Glass panel vacuum lifting equipment
- Heavy-duty packaging line pusher mechanisms
- Automotive welding fixture locking devices
Installation protocol:
Apply 24-29N·m torque to flange bolts using cross-tightening pattern.
Maintain 0.5-1mm clearance between rod end and load during alignment.
Perform 50 low-pressure break-in cycles before full operation.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-157X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
