Airtac AQK Dowel Pin Cylinder AQK50SAAA2-158X310
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-158X310 Rodless Cylinder Specifications
- Model: AQK50SAAA2-158X310
- Type: ISO15552 compliant rodless cylinder
- Bore size: 50mm
- Stroke: 310mm (full designation: 158=basic code, X310=stroke length)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable air cushion (both ends)
- Mounting type: Standard SA series - square body with side mounting slots
- Piston speed: 50-750 mm/s (optimal at 200-500 mm/s)
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / G1/8 optional
- Seal material: NBR (Nitrile rubber)
- Body material: Aluminum alloy (anodized)
- Sliding mechanism: Precision linear guide bearings
- Weight: 3.8kg ±2% (without accessories)
- Dimensions:
- Length: 470mm (basic length 158mm + stroke 310mm)
- Width: 62mm (including guide rails)
- Height: 50mm (profile height)
High-precision rodless cylinder with integrated magnetic sensor slot (T-slot on profile) for position feedback. Features double piston seals and wear-resistant guide mechanism, designed for heavy-duty cyclic operations. The compact profile enables space-saving installations in multi-axis systems.
- Palletizing robot Z-axis drives
- CNC machine tool automatic door systems
- Electronics PCB handling equipment
- Automated packaging line conveyors
- Glass panel transfer systems
Installation protocol:
Requires periodic lubrication (ISO VG32 pneumatic oil recommended).
Maintain 0.3-0.6 MPa working pressure for optimal seal performance.
Sensor cables must be routed through designated cable carriers to prevent abrasion.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-158X310 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
