Airtac AQK Dowel Pin Cylinder AQK50SAAA2-179X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-179X360 Rodless Cylinder Specifications
- Model: AQK50SAAA2-179X360
- Series: AQK-S (High Rigidity Precision Series)
- Bore size: 50mm
- Stroke: 360mm
- Mounting type: Double-ear mounting (SAAA2 code)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion
- Piston speed: 50–800 mm/s
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy cylinder tube, hard anodized piston rod
- Seal type: NBR seals (standard), optional FKM
- Weight: 3.85 kg (with standard accessories)
- Dimensions: 694mm(L) × 60mm(W) × 60mm(H) (full extension)
- Rod end thread: M12×1.25 (male)
- ISO standard: 15552 compliant
- Repeat positioning accuracy: ±0.5mm
High-precision rodless cylinder featuring dual-guide rod reinforcement and anti-rotation mechanism. The 360mm stroke version delivers exceptional lateral load capacity (up to 140N·m moment resistance) while maintaining <0.05mm/m alignment accuracy. Integrated magnet slots allow sensor mounting for position feedback.
- Robotic arm articulation in assembly lines
- Vertical lifting in CNC material handling
- Precision clamping in injection molding machines
- High-cycle automation in automotive welding jigs
- Packaging line product transfer systems
Installation protocol:
Ensure parallel alignment within 0.2mm/m tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side load exceeding 15% of maximum thrust capacity.
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-179X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
