Airtac AQK Dowel Pin Cylinder AQK50SAAA2-198X360
2. Titanium alloy-plated pin surface for significantly enhanced wear resistance;
3. Front cover integrates a metal wiper scraper to effectively remove debris and chips;
4. Multi-directional mounting flexibility with four-sided mounting holes on the mechanism body;
5. Peripheral sensor slots on the cylinder body enable tool-free sensor attachment.
Category: Pin Clamp Cylinders | Brand: AirTAC | Series: AQK
AirTAC AQK50SAAA2-198X360 Pin Cylinder Specifications
- Model: AQK50SAAA2-198X360
- Type: Double-acting pin-type cylinder
- Bore size: Ø50 mm
- Stroke: 198 mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable buffer at both ends
- Mounting: Standard foot mounting (ISO 15552 compatible)
- Port size: G3/8 (NPT1/4 optional)
- Piston rod thread: M16×1.5
- Material:
- Tube: Aluminum alloy with hard anodizing
- Piston rod: Chrome-plated steel
- Seals: NBR (Nitrile rubber)
- Weight: 3.85 kg (with standard accessories)
- Dimensions:
- Extended length: 360 mm
- Retracted length: 162 mm
- Body width: 64 mm
- Mounting height: 100 mm
High-precision industrial cylinder featuring integrated guide pins for enhanced lateral load capacity. The multi-lip seal design ensures ≤0.5 mm/s leakage rate under 0.5 MPa. Pre-lubricated for maintenance-free operation up to 3,000 km travel distance. Includes anti-rotation mechanism for precise positioning in automated systems.
- Automated clamping fixtures in CNC machining centers
- Precision press-fit operations in automotive assembly
- Vertical lifting mechanisms for conveyor systems
- Component positioning in semiconductor handling equipment
- Packaging machine ejection systems
Installation recommendation:
Maintain 0.05-0.1mm clearance between guide pins and mating parts.
Use M6×12 mounting screws torqued to 4.5 N·m. Lubricate rod end weekly
with ISO VG32 hydraulic oil in high-cycle applications (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | AQK50SAAA2-198X360 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | With Adjustment Shim 2mm |
