Airtac ASE Single Acting Plunger Type Compact Air Cylinder ASE100X20SB
$120.47
Regular price
$127.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ASE100X20SB
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliance with ISO 21287 standard ensures high mounting dimension compatibility;
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 5N·m.
For vertical mounting, install with rod end downward to prevent particle accumulation.
Allow 15mm minimum clearance around cylinder body for heat dissipation.
2. Threaded connection between cylinder body and front/rear covers delivers robust construction and easy maintenance;
3. Precision-machined bore with hard anodized treatment for superior wear resistance and extended service life;
4. Asymmetric bidirectional piston seal design combines compact dimensions with integrated oil reservoir functionality;
5. Space-saving profile achieves 50% more compact installation space compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots enable tool-free sensor installation;
7. Integrated cushioning system effectively absorbs residual energy from high-speed operations and mechanical rotation;
8. Multiple configurable mounting accessories available for diverse applications.
Category: Compact Cylinders | Brand: AirTAC | Series: ASE
AirTAC ASE100X20SB Single-Acting Compact Cylinder Specifications
- Model: ASE100X20SB
- Type: Single-acting spring return (push type)
- Bore size: Ø100 mm
- Stroke: 20 mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushion type: Rubber buffer (adjustable end cushion)
- Port size: PT1/4 (M5×0.8 optional)
- Mounting types: Basic type, front flange (MF1), rear flange (MF2)
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 2.5 kg ±5%
- Dimensions (L×W×H): 215mm × 114mm × 114mm (at fully retracted position)
- Stroke tolerance: +2.0mm
- Max theoretical thrust: 706N @0.63MPa
- Air consumption: 157cm³/stroke @0.5MPa
- Sensor compatibility: Built-in magnet for magnetic switch (D-A73 series)
Ultra-compact cylinder with space-saving design (40% shorter than standard cylinders), featuring a chrome-plated piston rod for enhanced corrosion resistance. The double-sealed structure prevents external contamination, while the precision honed cylinder tube ensures smooth operation. Requires ISO 8573-1 class 3 or cleaner compressed air.
Typical Applications:
- High-speed packaging machinery ejector systems
- Electronics assembly clamping devices
- Automated door locking mechanisms
- Textile machinery thread control
- Food processing press/release operations
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 5N·m.
For vertical mounting, install with rod end downward to prevent particle accumulation.
Allow 15mm minimum clearance around cylinder body for heat dissipation.
Maintenance cycle:
- Relubrication interval: Every 500km stroke or 6 months
- Rod seal replacement: Every 2 million cycles
- Full overhaul recommended after 10 million cycles
| Property | Property Value |
|---|---|
| sku | ASE100X20SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <20mm> |
