Airtac ASQ Series Single Acting Slim Cylinder ASQ12X10B
$20.43
Regular price
$27.93
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ASQ12X10B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
Installation note:
Maximum side load 0.3N. For vertical mounting, use stroke ≤80% of catalog value.
Lubricate with ISO VG32 turbine oil if using non-lubricated air supply.
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X10B Single-Acting Compact Cylinder Specifications
- Model: ASQ12X10B
- Type: Single-acting spring return (pneumatic advance)
- Bore size: 12mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Medium: Dry air (Lubricated or non-lubricated)
- Cushioning: Rubber buffer (Front end)
- Mounting type: Basic (No pre-fixed mounting)
- Material: Aluminum alloy barrel, Chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.12kg (Without accessories)
- Dimensions:
- Length: 43mm (Min. retracted length)
- Width: 20mm (Cylinder body diameter)
- Height: 12mm (Mounting base height)
- Port thread: M5×0.8 (Standard)
- Piston rod thread: M4×0.7 (External)
- Max. theoretical thrust: 10.2N @0.5MPa
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features a spring-return mechanism requiring only single air connection, with wear-resistant chromium plating and anti-rotation piston design. Requires 5μm filtered air (ISO 8573-1:2010 class 5).
Typical Applications:
- PCB handling robots in electronics assembly
- Micro-part clamping in watch manufacturing
- Valve actuation in portable medical analyzers
- Compact jig positioning systems
- Photovoltaic panel cleaning mechanisms
Installation note:
Maximum side load 0.3N. For vertical mounting, use stroke ≤80% of catalog value.
Lubricate with ISO VG32 turbine oil if using non-lubricated air supply.
| Property | Property Value |
|---|---|
| sku | ASQ12X10B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <10mm> |
