Airtac ASQ Series Single Acting Slim Cylinder ASQ12X15B
$21.37
Regular price
$28.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ASQ12X15B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS industrial standards;
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
Installation guidelines:
Mount using M4 screws (max torque 1.2N·m). Maintain 0.5mm minimum clearance between rod end and workpiece. For vertical installations, add external guide mechanism. Lubricate rod every 500km stroke travel.
Critical notes:
Do not exceed 1,200mm/s piston speed. Avoid side loads exceeding 2N. For pulsating applications (>5Hz), consult factory for spring life calculation.
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X15B Single-Acting Compact Cylinder Specifications
- Model: ASQ12X15B
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Built-in rubber buffer
- Port size: M5x0.8 (standard) / PT1/8 optional
- Mounting: Basic front flange (NF) / Optional side mount
- Piston material: Aluminum alloy with hard anodizing
- Rod material: SUS304 stainless steel
- Seal type: NBR rubber (standard) / Fluorine optional
- Weight: 0.12kg (without accessories)
- Dimensions: 80mm(L) × 40mm(W) × 40mm(H)
- ISO standard: 6432 compliant
- Lubrication: Pre-lubricated (Grease-free operation)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features corrosion-resistant construction with IP54 protection rating. The chrome-plated piston rod integrates a scraper to prevent contaminant ingress. Requires 5μm filtered air for optimal performance.
Typical Applications:
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Automated packaging machine clamps
- Semiconductor wafer processing equipment
- Compact door locking systems
Installation guidelines:
Mount using M4 screws (max torque 1.2N·m). Maintain 0.5mm minimum clearance between rod end and workpiece. For vertical installations, add external guide mechanism. Lubricate rod every 500km stroke travel.
Critical notes:
Do not exceed 1,200mm/s piston speed. Avoid side loads exceeding 2N. For pulsating applications (>5Hz), consult factory for spring life calculation.
| Property | Property Value |
|---|---|
| sku | ASQ12X15B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
