Airtac ASQ Series Single Acting Slim Cylinder ASQ12X20
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X20 Single-Acting Compact Cylinder Specifications
- Model: ASQ12X20
- Type: Single-acting spring return (piston type)
- Bore size: 12mm
- Stroke: 20mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (Rc1/8/NPT1/8 optional)
- Cushion type: Rubber buffer (non-adjustable)
- Mounting options: Basic type (no mount) / MF12 front flange / MY12 side rod eye
- Material: Aluminum alloy cylinder tube / Stainless steel piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: Approx. 72g (body only) / 98g (with accessories)
- Dimensions:
- Body length: 54mm
- Stroke-adjusted length: 54mm + stroke (74mm total)
- Width: 24mm (square body profile)
- Height: 24mm (square body profile)
- Rod end thread: M4x0.7
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features a spring-return mechanism requiring only single air connection, with corrosion-resistant construction for industrial environments. The square profile enables secure mounting and sensor attachment. Requires 5μm filtered air (ISO 8573-1:2010 Class 4) and lubrication (ISO VG32 recommended).
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Textile machinery thread control
- Beverage canning line gate controls
- Semiconductor wafer positioning stages
Installation notes:
- Max lateral load: 1.5N (at piston rod end)
- Align cylinder axis within ±2° of load direction
- Allow 0.5mm clearance for thermal expansion
- Use C-shaped wrench on flats (8mm across) for port tightening
| Property | Property Value |
|---|---|
| sku | ASQ12X20 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
