Airtac ASQ Series Single Acting Slim Cylinder ASQ12X20B
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X20B Single-Acting Compact Cylinder Specifications
- Model: ASQ12X20B
- Type: Single-acting spring return (push type)
- Bore size: 12mm (±0.1mm tolerance)
- Stroke: 20mm (adjustable cushion optional)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (1/8" NPT optional)
- Mounting style: Basic foot mounting (MF12)
- Cushion type: Fixed rubber buffer
- Seal material: Nitrile rubber (NBR) standard
- Weight: 0.12kg (excluding accessories)
- Dimensions: 60mm(L) × 25mm(W) × 25mm(H)
- Rod thread: M4x0.7 external thread
- Piston speed: 50–800mm/s (lubricated)
- ISO standard: 6432 compliant
Ultra-slim profile cylinder (13mm shorter than standard ISO models) with chromium-plated piston rod for corrosion resistance. Features integrated mounting slots for tool-less installation and low-friction seals optimized for high cycle rates (up to 10,000 cycles/day). Requires 5μm filtered air with ISO VG32 lubricator oil recommended.
- PCB handling robots in electronics assembly
- Paper feed mechanisms in office automation
- Clamping fixtures for micro-machining centers
- Vending machine door actuators
- Medical device positioning systems
- Textile machinery thread tension control
Installation guidelines:
Maintain 0.5–1mm clearance between rod end and load during alignment.
For vertical mounting, use orientation code "V" variant to prevent
seal wear from piston self-weight. Lubricate weekly in high humidity (>80% RH) environments.
| Property | Property Value |
|---|---|
| sku | ASQ12X20B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
