Airtac ASQ Series Single Acting Slim Cylinder ASQ12X5
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X5 Single-Acting Compact Cylinder Specifications
- Model: ASQ12X5
- Type: Single-acting spring return (thin series)
- Bore size: 12mm
- Stroke: 5mm (customizable up to 100mm)
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (dual ports)
- Mounting type: Through-hole (side mounting)
- Cushioning: Rubber buffer
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP40
- Weight: 42g ±2g
- Dimensions: 33mm(L) × 12mm(Bore) × 20mm(H)
- Rod thread: M4x0.7 external thread
- Max piston speed: 500mm/s
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features precision honed aluminum tube with hard anodized finish for wear resistance. The dual-port design allows flexible piping configurations. Includes built-in magnetic sensor groove (M5 slot) for position detection compatibility.
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical equipment
- Clamping mechanisms in SMT pick-and-place machines
- Vent control in medical analyzers
- Precision alignment systems in optical device assembly
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 0.3N·m.
For vertical mounting, position piston rod downward to prevent debris accumulation.
- Relubrication interval: Every 500,000 cycles
- Seal replacement: Every 2 million cycles (NBR seals)
- Spring life expectancy: 5 million cycles @ 0.5MPa
| Property | Property Value |
|---|---|
| sku | ASQ12X5 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
