Airtac ASQ Series Single Acting Slim Cylinder ASQ12X5S
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ12X5S Single-Acting Compact Cylinder Specifications
- Model: ASQ12X5S
- Type: Single-acting spring return (push type)
- Bore size: 12mm
- Stroke: 5mm (adjustable cushion)
- Operating pressure: 0.15–0.8 MPa
- Medium: Dry air (lubricated or non-lubricated)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Cushion type: Rubber buffer
- Mounting style: Basic type (no built-in mounts)
- Material: Aluminum alloy cylinder tube, stainless steel piston rod
- Seal material: NBR (nitrile rubber)
- Weight: ~0.12kg (without accessories)
- Dimensions: 35mm(W) × 20mm(H) × 50mm(L) (at fully retracted position)
- Piston rod thread: M4x0.7 (male thread)
- Max theoretical thrust: 9.8N @0.5MPa
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features precision-ground rod and double-sealed end caps for leakage prevention. Spring return mechanism enables fail-safe retraction during pressure loss. Requires 5μm filtered air with ISO 8573-1:2010 class 3.4.3 cleanliness.
- PCB board clamping in SMT machines
- Micro-part ejection in medical device assembly
- Lens positioning systems in optical equipment
- Valve actuation in portable analyzers
- Paper feed mechanisms in compact printers
Installation note:
Maintain minimum 0.5mm clearance between rod end and workpiece. For vertical mounting,
use guide mechanisms to prevent side load. Lubricate every 3 months under continuous operation.
| Property | Property Value |
|---|---|
| sku | ASQ12X5S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <5mm> |
