Airtac ASQ Series Single Acting Slim Cylinder ASQ16X10
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X10 Single-Acting Thin Cylinder Technical Details
- Model: ASQ16X10
- Type: Single-acting spring return (pneumatic advance)
- Bore size: 16mm
- Stroke: 10mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Port thread: M5x0.8 (standard) / Rc1/8 optional
- Cushioning: Rubber buffer (front end)
- Piston speed: 50–700 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel / Chrome-plated steel rod
- Seal type: NBR seals with wear-resistant ring
- Weight: 0.13kg (without accessories)
- Dimensions: 58mm(L) × 22mm(W) × 22mm(H) (minimum retracted length)
- Mounting options: Basic front flange (TF-16 accessory required)
- Rod end: Female M4 thread
- ISO standard: 6431 compliant
Ultra-compact pneumatic cylinder optimized for space-critical linear motion applications. Features a precision-ground rod with chrome plating (2μm thickness) for corrosion resistance. The anodized barrel surface (12μm coating) ensures durability in humid environments. Requires 40μm filtered air with ISO 8573-1:2010 Class 3.4.2 purity standards.
- PCB board clamping mechanisms in SMT machines
- Micro-assembly pick-and-place actuators
- Medical device lid positioning systems
- Photovoltaic panel cleaning robot joints
- Compact rotary index table drives
Installation protocol:
Apply Dow Corning Molykote 55 O-ring grease during assembly.
Maintain 0.5mm minimum lateral clearance during alignment.
For vertical mounting, use anti-drop lock nut ASQ-LK16.
| Property | Property Value |
|---|---|
| sku | ASQ16X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <10mm> |
