Airtac ASQ Series Single Acting Slim Cylinder ASQ16X15S
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X15S Single-Acting Compact Cylinder Specifications
- Model: ASQ16X15S
- Type: Single-acting spring return (piston type)
- Bore size: 16mm
- Stroke: 15mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: M5x0.8 (standard) with NPT1/8 adapter option
- Piston rod material: Stainless steel SUS304
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR (Nitrile Butadiene Rubber)
- Weight: 0.12kg (without accessories)
- Dimensions: 70mm(L) × 25mm(W) × 25mm(H) (at fully retracted position)
- Extended length: 85mm (stroke included)
- Mounting options: Basic front flange (MF1), optional side/axial mounts
- ISO standard: 6432 (DIN ISO 6432 compatible)
Ultra-slim profile cylinder optimized for space-constrained automation systems. Features corrosion-resistant construction with precision honed inner bore for smooth operation. The integrated cushioning mechanism reduces end-impact noise (≤65dB) while maintaining 0.8m/s maximum piston speed. Requires 5μm filtered air with ISO 8573-1:2010 class 3.4.3 standards.
- PCB handling robots in electronics manufacturing
- Medical device clamping mechanisms
- Packaging machine ejection systems
- Semiconductor wafer positioning stages
- Automated test equipment actuators
Installation guidelines:
Maximum side load ≤5N. Lubricate with ISO VG32 turbine oil if used without built-in lubricator.
For vertical mounting, use spring-down orientation to prevent piston self-weight extension.
| Property | Property Value |
|---|---|
| sku | ASQ16X15S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <15mm> |
