Airtac ASQ Series Single Acting Slim Cylinder ASQ16X20B
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X20B Single-Acting Compact Cylinder Specifications
- Model: ASQ16X20B
- Type: Single-acting spring return (piston type)
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer
- Mounting style: Basic type (axial mounting holes)
- Port size: M5×0.8 (standard) with NPT1/8 optional
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Protection rating: IP40 (dust protected)
- Weight: 0.13kg ±2%
- Dimensions:
- Total length (L): 50mm (at full retraction)
- Body width (W): 50mm (mounting bracket span)
- Height (H): 16mm (cylinder outer diameter)
- Rod end thread: M6×1.0
Ultra-slim profile pneumatic cylinder optimized for space-constrained automation systems. Features precision honed tube for smooth operation and anti-rotation design for stable linear motion. The wear-resistant rod guide bush extends service life up to 3,000km travel distance. Requires 5μm filtered compressed air with lubrication (ISO VG32 recommended).
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Medical device actuation systems
- Compact packaging machine ejectors
- Automated test equipment positioners
Installation note:
Maximum side load 2.5N. Use floating joints for angular misalignment over 0.5°.
Lubricate through air supply at 1 drop/m³ for optimal performance.
| Property | Property Value |
|---|---|
| sku | ASQ16X20B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
