Airtac ASQ Series Single Acting Slim Cylinder ASQ16X20S
2. Features C-shaped retaining rings for barrel-end cap fixation and riveted piston-rod connection, ensuring structural compactness and reliability;
3. Honed inner diameter barrel surface enhances wear resistance and operational longevity;
4. Extended guide distance on front cap optimizes alignment stability;
5. Space-saving design minimizes installation footprint;
6. Integrated sensor grooves along barrel periphery facilitate easy sensor mounting;
7. Versatile mounting accessories available for multiple configuration options;
Category: Compact Cylinder | Brand: AIRTAC | Series: ASQ Single-Acting Cylinder
AirTAC ASQ16X20S Single-Acting Compact Cylinder Specifications
- Model: ASQ16X20S
- Type: Single-acting (spring return)
- Bore size: 16mm
- Stroke: 20mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (1/8" NPT optional)
- Cushioning: Rubber buffer (adjustable)
- Seal material: NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃
- Mounting style: Basic type (MF1), optional foot/ flange mounts
- Rod material: Stainless steel (SUS304)
- Protection rating: IP40
- Weight: 0.15kg (without accessories)
- Dimensions: 70mm(L) × 40mm(W) × 40mm(H) (at fully retracted position)
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features a 25% shorter axial length than standard cylinders while maintaining equivalent output force (22N at 0.5MPa). The chrome-plated piston rod and precision honed tube ensure smooth operation with ≤0.5mm/s creep speed at cutoff pressure.
- PCB handling robots in electronics assembly
- Medical device actuation mechanisms
- Cartesian coordinate pick-and-place systems
- Compact packaging machine ejectors
- Semiconductor wafer processing equipment
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
Lubricate with ISO VG32 turbine oil if operating below -10℃. Cycle rate should not exceed 120cpm
for optimal seal life. For vertical mounting, use anti-rotation accessories (AR-16 series recommended).
| Property | Property Value |
|---|---|
| sku | ASQ16X20S |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <20mm> |
