Airtac ATE Single Acting Guided Compact Cylinder ATE100X10
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X10 Single-Acting Spring Return Compact Cylinder Specifications
- Model: ATE100X10
- Type: Single-acting spring return (push type)
- Bore size: Ø100mm
- Stroke: 10mm
- Operating pressure: 0.15–0.8 MPa
- Port size: PT1/4 (G1/8 optional)
- Cushion type: Adjustable air cushion
- Material: Aluminum alloy body, CR/SUS piston rod
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.85kg ±2%
- Dimensions: 186mm(L) × 100mm(W) × 100mm(H)
- Rod thread: M16×1.5
- Protection rating: IP65 (dust-tight & water jet resistant)
A space-optimized pneumatic actuator featuring double-guide rod stabilization and anti-rotation design. The hardened piston rod (HRC 35-40) ensures wear resistance in high-cycle applications. Includes magnetic piston for position sensing compatibility. Lubricator-free operation with built-in wear compensation.
- Vertical press mechanisms in packaging lines
- Clamping fixtures for CNC machine tools
- Material gate control in conveyor systems
- Automated door locking in cleanroom environments
- Position holding in semiconductor handling equipment
Installation note:
Maximum side load capacity 250N. For vertical mounting,
use counterbalance valve when handling suspended loads.
Recommended maintenance: Relubricate every 3 million cycles
using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ATE100X10 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <10mm> |
