Airtac ATE Single Acting Guided Compact Cylinder ATE100X25SB
$122.12
Regular price
$129.62
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE100X25SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation tips:
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X25SB Single-Acting Compact Cylinder Specifications
- Model: ATE100X25SB
- Type: Single-acting spring return (pull type)
- Bore size: 100mm
- Stroke: 25mm
- Operation: Air pressure to extend, spring return
- Operating pressure: 0.05–0.9 MPa
- Port size: G1/8 (NPT1/8 optional)
- Cushioning: Adjustable rubber buffer
- Temperature range: -20℃ to 80℃
- Seal material: NBR + PU combination
- Mounting style: Basic rear clevis (MB series compatible)
- Weight: 1.8kg ±2%
- Dimensions: 170mm(L) × 112mm(W) × 112mm(H)
- Rod thread: M10×1.25 external thread
- Max piston speed: 500mm/s
- Protection rating: IP54 (standard wiper design)
High-strength aluminum cylinder optimized for space-constrained industrial applications. Features dual-layer sealing (NBR for static/PU for dynamic parts) ensuring 500km+ service life under normal operation. Optional magnetic piston version (ATE100X25SB-M) available for position sensing.
Typical Applications:
- Clamping mechanisms in CNC fixtures
- Vertical lifting gates in packaging lines
- Actuation of medical sterilization chamber doors
- Precision positioning in semiconductor handling
- Ejection systems in injection molding machines
Installation tips:
- Use ISO VG32 hydraulic oil for lubrication when operating below -10℃
- Limit side load to ≤15% of maximum thrust capacity
- Maintain 0.3mm minimum clearance between rod end and stopper
- For vertical mounting, install with rod facing downward to prevent seal wear
| Property | Property Value |
|---|---|
| sku | ATE100X25SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
