Airtac ATE Single Acting Guided Compact Cylinder ATE100X5SB
$116.28
Regular price
$123.78
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ATE100X5SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for enhanced cross-brand installation compatibility;
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
Installation tip:
For vertical downward thrust applications, add an external guide mechanism.
Lubricate with ISO VG32 turbine oil during initial installation. Maximum side load: 15N.
2. Threaded connection between cylinder body and end covers ensures structural integrity and serviceability;
3. Precision-machined bore with hard anodized surface treatment delivers exceptional wear resistance and extended service life;
4. Asymmetric bidirectional piston sealing design with integrated oil reservoirs optimizes compact dimensions while maintaining lubrication efficiency;
5. Space-saving profile achieves 50% reduction in installation footprint compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-side sensor slots facilitate straightforward proximity switch integration;
7. Integrated shock-absorbing cushions effectively mitigate residual kinetic energy from high-speed and rotational applications;
8. Versatile mounting accessories available for multiple configurations.
Category: Compact Cylinders | Brand: AirTAC | Series: ATE Single-Acting Compact Cylinder
AirTAC ATE100X5SB Single-Acting Spring Return Compact Cylinder Specifications
- Model: ATE100X5SB
- Type: Single-acting (spring return), guided piston
- Bore size: Ø100 mm
- Stroke: 5 mm (standard short stroke)
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (dual auto switch ports) + G1/4 (air inlet)
- Cushioning: Rubber buffer + adjustable cushion screw
- Mounting type: Basic type (no foot) with front flange
- Piston material: High-grade aluminum alloy (hard anodized)
- Rod material: Stainless steel (SUS304)
- Seal type: NBR rubber (standard) / optional FKM
- Temperature range: -20℃ to 80℃
- Weight: 1.65 kg (excluding accessories)
- Dimensions: 153mm(L) × 100mm(W) × 100mm(H)
- Repeat accuracy: ±0.2 mm
- ISO standard: 6432 compliant
Ultra-compact short-stroke cylinder designed for space-constrained industrial automation systems. Features precision-guided piston movement with dual anti-rotation design, making it ideal for vertical mounting applications. The hardened piston rod surface (HRC 45-50) ensures extended service life in high-cycle operations. Requires 5μm filtered dry air.
Typical Applications:
- PCB clamping in SMT manufacturing
- Precision positioning in robotic gripper systems
- Valve actuation in pharmaceutical packaging lines
- Material ejection in high-speed stamping presses
- Lens positioning in optical equipment assembly
Installation tip:
For vertical downward thrust applications, add an external guide mechanism.
Lubricate with ISO VG32 turbine oil during initial installation. Maximum side load: 15N.
Maintenance:
Replace seals after 2,000km cumulative travel or every 5 years.
Use AirTAC AHD-LF2 grease for re-lubrication. Avoid silicone-based lubricants.
| Property | Property Value |
|---|---|
| sku | ATE100X5SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <5mm> |
