Airtac B01-MAC Series Special Purpose Cylinder B01-MAC50X200SCA
AirTAC B01-MAC50X200SCA Special Purpose Cylinder Specifications
- Model: B01-MAC50X200SCA
- Type: Compact ISO standard cylinder (double-acting)
- Bore diameter: 50 mm
- Stroke: 200 mm (±1.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning type: Adjustable hydraulic shock absorber (both ends)
- Port size: M5x0.8 (standard) / G1/8 optional
- Mounting style: MF2 (front flange with foot mounting holes)
- Rod material: Hard chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Seal material: NBR (Nitrile rubber) with wear-resistant ring
- Sensor slot: Built-in magnet compatible with proximity sensors (2 slots)
- Weight: 2.35 kg (without accessories)
- Dimensions:
- Length: 298 mm (full retraction)
- Width: 76 mm (flange mounting surface)
- Height: 50 mm (body diameter)
- Protection rating: IP65 (standard wiper seal)
- Lubrication: Pre-lubricated (DOP mist lubrication compatible)
High-precision industrial cylinder with integrated shock absorption, designed for repetitive heavy-load applications. Features triple chrome plating on piston rod for enhanced corrosion resistance in humid environments. The symmetrical mounting surface allows flexible installation in confined spaces. Requires air filtration of 5-40μm and dew point -20℃ below ambient temperature.
- Automated palletizing systems
- Plastic injection molding machine ejectors
- Automotive welding fixture positioning
- Food packaging line pusher mechanisms
- CNC machine tool clamping devices
Maintenance note:
Lubricate every 3 months under normal operation (ISO VG32 recommended).
Avoid lateral load exceeding 30% of maximum thrust capacity.
Magnetic sensor cables must maintain 10cm separation from power lines.
