Airtac B06-TR Battery-Specific Cylinder B06-TR10X15S
AirTAC B06-TR10X15S Battery-Optimized Cylinder Specifications
- Model: B06-TR10X15S (Battery Special Series)
- Type: Double-acting cylinder with integrated battery control circuit
- Bore size: Ø10mm
- Stroke: 15mm (Standard) ±0.5mm tolerance
- Operating pressure: 0.05–0.7 MPa (Ultra-low pressure operation)
- Battery compatibility: 3.7V-6V DC (Li-ion/18650 cells preferred)
- Current draw: 85mA @ 4.2V (Peak during actuation)
- Piston speed: 50-500mm/s (Speed controller optional)
- Rod end: M4×0.7 female thread (Stainless steel insert)
- Seal material: Environmentally resistant HNBR
- Temperature range: -10℃ to 60℃ (Non-freezing conditions)
- Protection rating: IP54 (Dust & splash resistant)
- Weight: 180g ±5g (Including mounting accessories)
- Dimensions: 110mm(L) × 28mm(W) × 28mm(H) (Compact cube design)
- Cushion type: Elastic rubber bumper (Adjustable stroke end)
- Repeat accuracy: ±0.1mm (With position feedback option)
Ultra-compact pneumatic actuator specifically engineered for battery-powered automation systems. Features gold-plated signal contacts for reliable low-voltage operation and patented "EcoPulse" PWM control technology reducing energy consumption by 40% compared to standard models. Integrated pressure compensation maintains consistent force output during battery voltage drop.
- Portable medical diagnostic equipment
- AGV (Automated Guided Vehicle) clamping mechanisms
- Solar-powered agricultural actuators
- IoT-enabled smart lock systems
- Robotic grippers in field service robotics
- Battery-operated packaging machines
Installation Protocol:
Requires minimum 2.5mm² power cables for stable current delivery.
For optimal battery life, maintain 20-80% duty cycle and implement
sleep mode (<1mA standby current available). Lubricate quarterly
with ISO VG15 pneumatic oil in high-cycle applications.
- Control method: 3.3V/5V TTL compatible
- Feedback options: Hall-effect position sensor (I²C output)
- Emergency stop: Built-in low-voltage cutoff (2.8V ±0.2V)
| Property | Property Value |
|---|---|
| sku | B06-TR10X15S |
