Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB
The AirTAC Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB is a genuine double acting ISO 21287 compact air cylinder with a Ø32mm bore and 20mm stroke, 1/8" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ32 mm
- Stroke20 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM8×1.25
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB
This B52-ACE32X20SB is a double acting ISO 21287 compact cylinder from AirTAC, delivering a 402.1 N push and 345.6 N pull at 0.5 MPa. The B52- prefix designates the copper-free (copper-prohibited) build, suited for lines where copper alloys are not permitted, such as ammonia systems or certain electronics plants; the exact material substitutions should be confirmed with us.
Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, fitting tight jigs and guards. With the optional -S magnet fitted, this unit works with CMSE or DMSE switches; for a real workload, plan on about 241 N (0.6 times the push force) as a safe working load at 0.5 MPa, which translates to lifting roughly 24.5 kg vertically with a 2:1 margin.
Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB Technical Specifications
| Model | Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø32 mm |
| Stroke | 20 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M8×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 200 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | 484 N |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 32 | Bore size in mm. |
| ×20 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB Is Used
PCB Handling Gripper
In a PCB assembly line, this 20 mm stroke cylinder actuates a gripper to lift and place boards, with the 402.1 N push handling the weight and the compact body fitting between conveyor rails.
Battery Tab Press
For a battery tab bending station, the B52-ACE32X20SB provides a controlled 20 mm stroke to press tabs, and the copper-free build avoids contamination in sensitive electronics manufacturing areas.
Sorting Gate Actuator
On a small sorting conveyor, this cylinder drives a diverter gate with a 20 mm stroke, cycling at up to 500 mm/s to redirect packages, while the magnet enables position sensing for PLC control.
Is the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB the Right Cylinder?
For a lighter duty, consider the ACE25X20 with a 245.4 N push at 0.5 MPa, while the ACE40X20 offers a 628.3 N push for heavier tasks. This 32 mm bore model is a balanced choice for medium-force automation. Note that a plain ACE does not hold its position when air is lost; for load holding, add a rod lock or pilot check valve. The male rod thread (B) and the fitted magnet (S) make it ready for sensor feedback and direct coupling.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE32X20SB FAQ
At 0.5 MPa, the push force is 402.1 N and the pull force is 345.6 N. At 0.7 MPa, push is 563 N and pull is 483.8 N. The theoretical maximum force is 82 kgf at 1.0 MPa.
The B52- prefix indicates a copper-free (copper-prohibited) build, for environments where copper alloys are not allowed; confirm exact substitutions with us. The ISO 21287 body is about 50% shorter than an ISO 15552 profile cylinder, saving space in tight fixtures, and the fixed TPU bumper absorbs end-of-stroke impact without needing adjustment.
