Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB
The AirTAC Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB is a genuine double acting ISO 21287 compact air cylinder with a Ø50mm bore and 40mm stroke, 1/8" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ50 mm
- Stroke40 mm
- Port size1/8"
- Acting typeDouble acting
- Rod threadM10×1.5
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB
This B52-ACE50X40SB is a double acting ISO 21287 compact cylinder, pushing 981.7 N and pulling 881.2 N at 0.5 MPa. The B52- prefix marks AirTAC's copper-free (copper-prohibited) build, ideal for lines where copper alloys are not permitted, such as ammonia systems; confirm exact material substitutions with us.
The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, fitting tight jigs and guards. With the optional -S magnet fitted, CMSE or DMSE switches can be mounted for position sensing. For real work, plan for about 589 N (60 kg) at 0.5 MPa, or about 60 kg vertical lift with a 2:1 margin.
Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB Technical Specifications
| Model | Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø50 mm |
| Stroke | 40 mm |
| Acting type | Double acting |
| Port size | 1/8" |
| Rod thread | M10×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 250 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø50mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 982 N | 881 N |
| 0.7 MPa | 1374 N | 1234 N |
| Max (@1.0 MPa) | 200 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 50 | Bore size in mm. |
| ×40 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB Is Used
Fixture Clamping
Use in a jig to clamp a 50 kg workpiece during CNC drilling, relying on the 981.7 N push force at 0.5 MPa.
Battery Line Stop
In a battery assembly line, this copper-free cylinder actuates a stop gate, avoiding copper contamination near electrolyte handling.
Carton Ejector
Eject filled cartons from a conveyor onto a chute, with the 40 mm stroke providing quick, repeatable motion at speeds up to 500 mm/s.
Is the Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB the Right Cylinder?
For a lighter load, consider the 40 mm bore ACE40X40 with 628.3 N push, or step up to the 63 mm bore ACE63X40 for 1558.6 N push at 0.5 MPa. This 50 mm bore with 40 mm stroke suits short-stroke clamping or pressing tasks. The male rod thread (B) simplifies mounting with rod-end accessories, and the fitted magnet enables CMSE or DMSE sensors for position feedback.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac B52-ACE Non-Copper Compact Cylinder B52-ACE50X40SB FAQ
At 0.5 MPa, push is 981.7 N and pull is 881.2 N. At 0.7 MPa, push is 1374.4 N and pull is 1233.7 N. Theoretical maximum force is 200.2 kgf at 1.0 MPa.
B52- is AirTAC's copper-free (copper-prohibited) version, for applications where copper alloys are not allowed, such as ammonia systems; confirm material details with us. The ISO 21287 compact body is about 50% shorter than an ISO 15552 profile cylinder, saving space in tight fixtures. The fixed TPU bumper absorbs end-of-stroke impact, and the optional -S magnet enables CMSE or DMSE sensors.
