AirTAC ACQJ Series · JIS Compact Adjustable-Stroke Cylinder

Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB

The AirTAC B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB is a genuine double-acting COMPACT (JIS) cylinder with an EXTERNAL adjustable stop on the extend stroke — a Ø50mm bore and 75mm full stroke. Turn the stop to fine-tune the end position on the machine without changing parts.

  • BoreØ50 mm
  • Full stroke75 mm
  • Port sizePT1/4
  • Adjuster threadM16×1.5
$77.44 $86.35Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB

The B52-ACQJ50X75-20SB is the copper-free (copper-prohibited) version of AirTAC's ACQJ50X75-20SB adjustable-stroke compact cylinder. This double-acting unit uses an external threaded stop with a lock nut on the rod-end side to limit rod extension, letting you fine-tune the extend end position directly on the machine without disassembly. With a 75mm full stroke and a 20mm adjustable window, the usable extend range runs from 55mm up to 75mm, while the retract stroke remains unaffected.

The 20mm rod with M18x1.5 male thread couples directly to your load. Fixed elastomer bumpers at both ends absorb impact, and the built-in -S magnet works with both reed and electronic switches. The B52- prefix indicates copper-free construction for lines where copper alloys are prohibited; confirm exact material substitutions with us.

Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB Technical Specifications

ModelAirtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB
SeriesACQJ JIS compact adjustable-stroke cylinder
Bore sizeØ50 mm
Full stroke75 mm
Adjuster threadM16×1.5
Port sizePT1/4
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
Rod threadM10×1.5 (F) / M18×1.5 (B)

Specifications follow the official AirTAC ACQJ datasheet. The adjustable stop shortens the EXTEND stroke only; ACQJ is double-rod, so push is lower than a standard ACQ of this bore. Adjustable window options: 10/20/30/40/50/75/100 mm.

Theoretical Output Force (Ø50mm)

PressurePush forcePull force
0.5 MPa825 N825 N
0.7 MPa1155 N—
Max (@1.0 MPa)168 kgf

ACQJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod ACQ push of the same bore. Actual usable force is lower due to friction; size with a safety margin.

Model Code: Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB

ACQJJIS compact double-acting ADJUSTABLE-STROKE cylinder series.
50Bore size in mm.
×75Full stroke length in mm.
-0Adjustable window in mm (extend stroke can be shortened by up to this).
S / BMagnet (S) / male-thread rod (B); omit for none / female thread.

Thread: PT standard (G / NPT available). Related: ACQ (fixed stroke), ACQD (double rod), TACQ (guided / non-rotating).

Where the Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB Is Used

precision_manufacturing

Fixture Setup Variation

In CNC machining fixtures, use the 55-75mm adjustable range to compensate for workpiece tolerance stack-up, setting the extend stop once per batch without swapping cylinder parts.

swap_horiz

Product Changeover Stops

On packaging lines handling different box depths, turn the external adjuster to reposition the extend stop between product runs, cutting changeover time from minutes to seconds.

factory

Trial End Positions

During automated assembly machine commissioning, dial in the exact extend position for gripper pickup points across the 55-75mm range, then lock the nut to secure the setting.

Is the Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB the Right Cylinder?

Choose this B52-ACQJ50X75-20SB when you need 75mm of travel with a 20mm on-machine adjustment range. If your application only needs a fixed stroke, a standard ACQ50X75 may suffice at lower cost. Ordering essentials: bore 50, full stroke 75, window 20, magnet (-S), male rod thread (-B), and PT ports.

Quick checklist

  • ✓ Need on-machine end-position tuning?
  • ✓ Full stroke and adjust window (mm)
  • ✓ Force at your working pressure
  • ✓ Magnet (S) for sensors?
  • ✓ Female (blank) or male (B) rod thread
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the adjuster nut after setting the stop.
  • check The stop limits the EXTEND stroke only.
  • check Avoid side load on the short piston rod.
  • check Installation by qualified personnel per AirTAC docs.

Airtac B52-ACQJ Copper-Free Ultra-Thin Air Cylinder B52-ACQJ50X75-20SB FAQ

Full stroke is 75mm with a 20mm adjustable window, giving a usable extend range of 55-75mm. Retract stroke is unaffected by the adjuster.

The external threaded stop with lock nut limits rod extension, letting you shorten the extend stroke by up to 20mm on-machine; force stays identical to a standard ACQ since piston area is unchanged. The B52- prefix marks the copper-free (copper-prohibited) build of ACQJ50X75-20SB, for lines where copper alloys are not allowed-confirm specific material substitutions with us.
