Airtac B52-HLQ Copper-Free Precision Slide Table Cylinder B52-HLQ8X40SA
AirTAC B52-HLQ8X40SA Copper-Free Precision Slide Table Cylinder Specifications
- Full Model: B52-HLQ8X40SA
- Series: B52-HLQ (Copper-Free Series)
- Bore Size: Ø8mm
- Stroke: 40mm (customizable 10-300mm)
- Structure: Twin-guide rail sliding table
- Material: Aluminum alloy body with hardened stainless steel shafts
- Seals: Polyurethane + NBR combination
- Operating Pressure: 0.1-0.8 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable rubber buffers (both ends)
- Position Detection: Magnet embeddable (T-slot for sensor mounting)
- Repeat Positioning Accuracy: ±0.01mm
- Weight: 0.45kg (excluding accessories)
- Dimensions: 150mm(L) × 32mm(W) × 34mm(H) (at mid-stroke)
- Mounting: Standard M4 threaded holes on base (4 places)
- Surface Treatment: Anodized aluminum body, chrome-plated rods
High-precision linear actuator with copper-free construction, ideal for semiconductor and electronic manufacturing environments. Features dual linear ball bearings for smooth motion (friction coefficient <0.003) and integrated T-slot for optical sensor mounting. Includes anti-rotation mechanism for stable vertical/horizontal operation.
- PCB component placement machines
- Laser marking equipment positioning
- Medical device assembly lines
- Cleanroom automation systems
- Precision dispensing/pick-and-place units
Installation notes:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain perpendicularity within ±0.5° during mounting.
For vertical installations, use counterbalance valves.
Copper content <0.5% in all wetted parts.
| Property | Property Value |
|---|---|
| sku | B52-HLQ8X40SA |
