Airtac B52-HLQL Copper-Free Precision Slide Table Cylinder B52-HLQL12X20SAS
AirTAC B52-HLQL12X20SAS Copper-Free Precision Slide Table Cylinder Specifications
- Model: B52-HLQL12X20SAS
- Series: B52-HLQL (Copper-Free Design)
- Bore Size: Φ12mm
- Stroke: 20mm
- Operating Pressure: 0.05-0.9 MPa
- Temperature Range: -10℃ to 80℃
- Buffer Type: Adjustable Rubber Cushion
- Seal Material: Special NBR (Copper-Free Formula)
- Repeat Positioning Accuracy: ±0.01mm
- Guide Mechanism: Dual Linear Ball Bearings
- Rod End Type: Double Shaft End (SAS Configuration)
- Magnet Type: Built-in Magnetic Ring (S Series)
- Port Size: M5x0.8
- Weight: 0.82kg
- Dimensions: 78mm(L) × 42mm(W) × 48mm(H)
- Protection Rating: IP54
- Lubrication Requirement: Pre-lubricated (No re-lube needed for 1,000km travel)
Ultra-precision guided cylinder with copper-free construction, featuring chromium-plated stainless steel rod and aluminum alloy body. The dual-axis design provides exceptional lateral load capacity (up to 1.5N·m moment resistance) while maintaining smooth linear motion. Integrated sensor slots support inductive proximity switch mounting (SN04-N/SN04-P compatible).
- Semiconductor wafer handling robots
- Medical device assembly lines
- Optical lens positioning systems
- Lithium battery production equipment
- Cleanroom automation (ISO Class 5 compatible)
Installation note:
Requires 5μm filtered air supply with dew point -20℃ below ambient.
Mounting surface flatness ≤0.05mm/m. Avoid side load exceeding 15N during operation.
For vertical mounting, use counterbalance valves for speed control.
| Property | Property Value |
|---|---|
| sku | B52-HLQL12X20SAS |
