Airtac B52-HLQL Copper-Free Precision Slide Table Cylinder B52-HLQL16X100SBF
AirTAC B52-HLQL16X100SBF Copper-Free Precision Slide Table Cylinder Specifications
- Model: B52-HLQL16X100SBF
- Series: B52-HLQL (Copper-free design)
- Bore size: 16mm
- Stroke: 100mm (±0.5mm tolerance)
- Mounting type: Square flange base (SBF)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber bumper (both ends)
- Seal material: Special copper-free NBR compound
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Repeat positioning accuracy: ±0.01mm
- Rod material: Hard chrome-plated stainless steel
- Weight: 0.82kg (excluding accessories)
- Dimensions: 180mm(L) × 45mm(W) × 45mm(H)
- Protection rating: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (maintenance-free for 5,000km)
Ultra-precision guided cylinder with copper-free construction, featuring dual linear ball bearings for exceptional straightness (≤0.05mm/m). The anodized aluminum body prevents particle shedding in clean environments. Integrated T-slot mounting enables modular assembly with 95% of AirTAC's automation components.
- Semiconductor wafer handling robots
- Optical lens coating machinery
- Pharmaceutical blister packaging lines
- 3C product testing jigs
- High-speed PCB drilling systems
Installation tip:
Use M4x8 stainless steel screws for mounting (torque ≤1.2N·m).
For vertical applications exceeding 1m/s speed, install an external shock absorber.
Copper restriction:
Mandatory for oxygen-rich or ammonia environments (ISO 8573-1 Class 0 compliance).
Incompatible with silicone-based lubricants - use PFPE grease only.
