Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA
The AirTAC Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA is a genuine double acting standard round-body mini air cylinder with a Ø0mm bore and 175mm stroke, PT/G air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ0 mm
- Stroke175 mm
- Port sizePT/G
- Acting typeDouble acting
- Rod thread
- CushionFixed anti-impact bumper pads
About the Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA
A compact double-acting round mini cylinder with a 25 mm bore and a 175 mm stroke, the MA25X175SCA delivers 245.3 N of push and 206.1 N of pull at 0.5 MPa, rising to 343.4 N of push at 0.7 MPa. Fixed anti-impact bumper pads soften the contact at each stroke end without forming an adjustable cushion. Because the piston magnet comes as standard, a CMSG, DMSG or EMSG switch clips straight onto the barrel for end-of-stroke signalling. For sizing, treat roughly 147 N at 0.5 MPa as the realistic working effort, which equals about a 12 kg vertical lift once a 2:1 margin is applied. The stainless-steel barrel paired with a 20 um hard-chrome plated rod shrugs off damp washdown corners far better than painted-steel minis, and the riveted CA pivot back cover lets a link or eye swing freely without add-on brackets.
Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA Technical Specifications
| Model | Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA |
|---|---|
| Series | MA mini cylinder |
| Bore size | Ø0 mm |
| Stroke | 175 mm |
| Acting type | Double acting |
| Port size | PT/G |
| Rod thread |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø0mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 0 N | 0 N |
| 0.7 MPa | 0 N | 0 N |
| Max (@1.0 MPa) | 0 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA
| MA | Standard round-body mini cylinder (double-acting). |
|---|---|
| 0 | Bore size in mm. |
| ×175 | Stroke length in mm. |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA Is Used
Date-code stamping on cosmetic tubes
The 175 mm stroke reaches into a shallow indexing nest while the 245.3 N push at 0.5 MPa presses an ink wheel or hot stamp onto each tube face.
Carton gate on a bottling conveyor
A CA pivot link swings the gate between two lanes; about 147 N of usable effort moves carton batches without oversizing the actuator.
Blister tray ejection on a thermoformer
Retracting with 206.1 N of pull at 0.5 MPa, the cylinder strips formed trays cleanly off the mould plate as the platen opens.
Is the Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA the Right Cylinder?
At 0.5 MPa the push ladder runs 157.0 N on the 20 mm bore, 245.3 N here and 402.2 N on the 32 mm bore, so step up a size when the duty needs more than about 147 N of sustained effort. Remember that a plain MA drifts as soon as the valve centres or air is lost; fit a rod lock or pilot check valve where the load must stay parked. The CA pivot back cover suits swing links and toggle mechanisms, while FA flange, LB foot or SDB pivot brackets bolt on for fixed mounting. Over a 175 mm stroke, keep side loads off the M10x1.25 male rod thread by guiding the payload externally.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Bumper models: keep speed within the rated range.
- check Installation by qualified personnel per AirTAC docs.
Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA25X175SCA FAQ
At 0.5 MPa it pushes with 245.3 N and pulls with 206.1 N; at 0.7 MPa push reaches 343.4 N. The theoretical maximum is 50 kgf at 1.0 MPa. Operating pressure spans 0.15-1.0 MPa (22-145 psi), proof pressure is 1.5 MPa (215 psi), and rod speed runs 30-800 mm/s.
Yes. Every MA-series piston carries a magnet as standard, so CMSG, DMSG and EMSG switches mount directly on the stainless barrel with no special-order piston. This 25 mm bore uses 1/8 in PT ports and an M10x1.25 male rod thread.
