Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM
The AirTAC Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM is a genuine double acting standard round-body mini air cylinder with a Ø0mm bore and 350mm stroke, PT/G air ports and a stainless-steel barrel with a hard-chrome-plated rod for reliable, mildly corrosion-resistant service.
- BoreØ0 mm
- Stroke350 mm
- Port sizePT/G
- Acting typeDouble acting
- Rod thread
- CushionFixed anti-impact bumper pads
About the Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM
A 32 mm bore round-body mini cylinder with a generous 350 mm stroke, the MA32X350SCM runs double acting on clean dry air and lands in the mid force class: 402.2 N pushing and 345.6 N pulling at 0.5 MPa (72.7 psi). At a working margin of 60 percent you can count on roughly 241 N of usable push, which is enough to lift a part of about 20 kg vertically with a 2:1 safety factor. The stainless-steel round barrel paired with a 20 um hard-chrome plated rod resists washdown and damp shop air far better than painted minis, while the riveted aluminium covers keep the envelope tight. Every unit carries fixed anti-impact bumper pads that soften stroke-end deceleration, and the magnet is built in as standard, so CMSG, DMSG or EMSG switches mount straight onto the tube.
Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM Technical Specifications
| Model | Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM |
|---|---|
| Series | MA mini cylinder |
| Bore size | Ø0 mm |
| Stroke | 350 mm |
| Acting type | Double acting |
| Port size | PT/G |
| Rod thread |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Fixed anti-impact bumper pads |
| Max standard stroke | Up to 500 mm |
Specifications follow the official AirTAC MA-series datasheet. Barrel: stainless-steel tube (round-body, riveted rolling-packed construction); piston rod: carbon steel with 20µm hard-chrome plating; covers: aluminium alloy. Thread options: PT (blank) / G / NPT. Every MA-series cylinder ships with a built-in magnet for CMSG / DMSG / EMSG position sensors.
Theoretical Output Force (Ø0mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 0 N | 0 N |
| 0.7 MPa | 0 N | 0 N |
| Max (@1.0 MPa) | 0 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM
| MA | Standard round-body mini cylinder (double-acting). |
|---|---|
| 0 | Bore size in mm. |
| ×350 | Stroke length in mm. |
| -S | Built-in magnet for CMSG / DMSG / EMSG sensors (standard on MA series). |
| CA / U / CM | Back-cover type: CA pivot, U flat-end, CM round-end. |
MA-family variants: MA / MAC (double acting ±cushion), MSA / MTA (single acting push / pull), MAD / MACD (double rod ±cushion), MAJ / MACJ (adjustable stroke ±cushion), MAR (cushioned with integrated F/U mount). Mounting accessories: FA flange, LB foot, SDB pivot; plus I and Y knuckles. Thread PT (blank) / G / NPT.
Where the Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM Is Used
Palletizer parts pusher
A 350 mm reach lets this 32 mm cylinder sweep cartons across the full depth of a palletizing station, with 402.2 N of push at 0.5 MPa handling off-center boxes without stalling.
Fixture lift on assembly benches
Raising a 20 kg weld fixture between stations is comfortable territory here - the vertical-lift margin of the 402 N bore keeps the motion smooth while the magnet feeds a DMSG switch for top-of-stroke signaling.
CNC enclosure guard slide
Sliding a machine guard door over a 350 mm opening suits this stroke; the fixed bumper pads cushion the door at each end of travel, and the stainless barrel tolerates coolant mist near the spindle.
Is the Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM the Right Cylinder?
Check the force band before committing: a 25 mm bore MA delivers 245.3 N at 0.5 MPa, while stepping up to 40 mm buys you 628.3 N, so 32 mm sits squarely between the two. Remember this cylinder releases its load the moment air is vented or the valve centres - for a load that must stay in place, pair it with a rod lock or pilot check valve. The SCM suffix gives you the CM round-end back cover, and FA flange, LB foot or SDB pivot mounts bolt on without machining. With 350 mm of travel, support the stroke laterally or guide the load externally; a 12 mm rod can buckle or bow if side loads ride on it. The 1/8" ports suit standard PT fittings.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT / G / NPT)
- ✓ Magnet (-S) is standard for sensors
- ✓ Back cover (CA/U/CM) & mount (FA/LB/SDB)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Do not dismantle the riveted front/back covers.
- check Bumper models: keep speed within the rated range.
- check Installation by qualified personnel per AirTAC docs.
Airtac B52-MA Copper-Free Stainless Steel Mini Cylinder B52-MA32X350SCM FAQ
At 0.5 MPa (72.7 psi) this 32 mm bore pushes with 402.2 N and pulls with 345.6 N. Raise supply to 0.7 MPa (101.5 psi) and push climbs to 563.0 N with 483.8 N on the pull stroke. The theoretical maximum is 82.0 kgf at 1.0 MPa. Operating pressure spans 0.15-1.0 MPa (22-145 psi) with proof pressure of 1.5 MPa (215 psi), rod speed 30-800 mm/s, and air filtered to 40 um.
The CM round-end cover gives a compact, flush rear face that tucks into tight machine frames where a pivot eye would snag. Combine it with an FA flange, LB foot or SDB pivot bracket to lock the 350 mm stroke in place, and the standard built-in magnet accepts CMSG, DMSG or EMSG reed switches without ordering a special piston.
