Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-149X290
AirTAC BAQK50SAAA-149X290 Clamp Type Stud Cylinder Specifications
- Model: BAQK50SAAA-149X290
- Type: Double-acting clamp cylinder with integrated stud
- Bore size: Ø50 mm
- Stroke: 290 mm
- Operating pressure: 0.1–1.0 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Foot-mounted with reinforced clamp bracket
- Port size: Rc1/4 (G1/4 optional)
- Piston rod thread: M16×1.5
- Material: Aluminum alloy barrel, CR12MoV piston rod
- Seal material: NBR with wear-resistant ring
- Protection rating: IP54
- Weight: 3.8 kg ±2%
- Dimensions: 587mm(L) × 149mm(W) × 75mm(H)
High-rigidity clamp cylinder featuring anti-rotation stud design for precision linear motion control. The hexagonal piston rod prevents rotation during operation, with hardened chrome-plated surface (HRC 45-50) for wear resistance. Includes built-in magnet for position sensing compatibility.
- Precision fixturing in CNC machining centers
- Material handling systems requiring anti-torsion stability
- Automated welding equipment position locking
- Press tooling alignment mechanisms
- Robotic arm end-effector positioning
Installation note:
Ensure parallel alignment of clamp brackets within 0.2mm tolerance.
Lubricate piston rod with ISO VG32 hydraulic oil before initial operation.
Maximum side load capacity: 250N at full extension.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-149X290 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
