Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-177X340
AirTAC BAQK50SAAA-177X340 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-177X340
- Type: Double-acting clamp pin cylinder
- Bore size: 50mm
- Stroke: 340mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Buffer type: Adjustable rubber cushion (both ends)
- Mounting style: Standard foot + front flange
- Port size: G1/2 (ISO standard)
- Seal material: NBR + PU composite
- Piston rod material: Hard anodized aluminum alloy
- Protection rating: IP54 (standard wiper design)
- Weight: ~5.8kg (without accessories)
- Dimensions: 340mm(Stroke) × 177mm(Total length) × 68mm(Height) × 50mm(Bore width)
Heavy-duty clamp cylinder with integrated anti-rotation pin mechanism, featuring high rigidity guide structure for precision linear motion. The dual piston seal design ensures stable gripping force up to 980N at 0.5MPa. Optimized for vertical/horizontal mounting in high vibration environments with ±0.5mm repeat positioning accuracy.
- Automated fixture clamping in CNC machining centers
- Press machine tooling plate positioning
- Injection molding ejection systems
- Pallet locking in logistics sorting lines
- Robotic welding jig stabilization
Installation protocol:
Always align clamp pins with mating holes before pressurization.
Lubricate with ISO VG32 hydraulic oil during assembly.
Allow 20mm clearance around cylinder body for heat dissipation during continuous operation.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-177X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
