Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-178X340
AirTAC BAQK50SAAA-178X340 Clamp-Type Pin Cylinder Specifications
- Model: BAQK50SAAA-178X340
- Type: Double-acting clamp pin cylinder
- Bore size: Ø50 mm
- Stroke: 340 mm
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Through-hole clamp type (ISO 15552 compatible)
- Port size: G1/2 (ISO 228/1 standard)
- Piston rod thread: M20×1.5
- Material: Aluminum alloy body, hard anodized surface
- Rod material: Carbon steel with hard chrome plating
- Seals: NBR (standard) / Optional FKM for high temp
- Weight: 3.8 kg (dry, without accessories)
- Dimensions: 700mm(L) × 78mm(W) × 78mm(H)
- Repeat accuracy: ±0.2 mm
- Max lateral load: 180 N at full extension
- ISO speed range: 50–800 mm/s
Heavy-duty clamp cylinder with integrated anti-rotation pin mechanism, designed for precision linear motion in high-moment applications. Features triple sealing system (rod wiper + primary seal + buffer seal) and dual guide bushings for enhanced lateral load capacity. The hardened piston rod and aluminum construction ensure durability in continuous operation cycles.
- Automated welding fixture positioning
- Die-casting machine core-pulling mechanisms
- Press tool alignment systems
- Heavy conveyor gate actuation
- Robotic arm end-effector clamping
Installation note:
Requires perpendicular mounting surface with flatness ≤0.1mm. Use torque wrench for clamp bolts (35-40 N·m).
Lubricate rod weekly with ISO VG32 hydraulic oil in dusty environments.
Critical parameter:
Maximum side load capacity reduces by 15% when operating at temperatures above 60℃.
Always maintain air supply dew point 10℃ below minimum operating temperature.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-178X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
