Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-198X340
AirTAC BAQK50SAAA-198X340 Clamp Pin Cylinder Specifications
- Model: BAQK50SAAA-198X340
- Type: Double-acting clamp pin cylinder (ISO 6432 compliant)
- Bore size: Ø50 mm
- Stroke: 198 mm (Standard) × 340 mm (Extended clamping range)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting type: Dual through-hole base mounting (M8×1.25)
- Port size: G1/8 (ISO 1179-1 standard)
- Operating temperature: -10℃ to 80℃
- Rod material: Hard chrome-plated steel (HCP)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber) with wear-resistant ring
- Weight: 3.8 kg ±2% (including mounting accessories)
- Dimensions:
- Total length: 728 mm (Full extension)
- Body diameter: Ø60 mm
- Mounting base: 90mm(W) × 50mm(H)
- Rod thread: M20×1.5 (Front end)
High-precision clamping cylinder with reinforced rod locking mechanism, featuring 3-stage position detection slots for precise motion control. The X340 extended version incorporates a dual-stroke design for multi-position workholding applications. Includes anti-rotation guide and IP67-rated dust wipers.
- CNC machine tool automatic clamping systems
- Automotive welding fixture positioning
- Die-casting mold core pulling mechanisms
- Heavy-load pallet locking in AS/RS
- Precision gear assembly presses
Installation notes:
- Requires 5-7 bar filtered/lubricated air (ISO 8573-1 class 3.4.2)
- Maximum side load capacity: 450N at 0.5MPa
- Recommended re-lubrication interval: 500,000 cycles
- Mounting torque: 22-25 N·m for base screws
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-198X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
