Airtac BAQK Clamp Type Pin Cylinder BAQK50SAAA-199X340
AirTAC BAQK50SAAA-199X340 Clamping Pin Cylinder Specifications
- Full Model: BAQK50SAAA-199X340
- Type: Double-acting clamping pin cylinder (rod lock type)
- Bore size: Ø50 mm (±0.1mm tolerance)
- Rod diameter: Ø20 mm (chrome-plated steel)
- Stroke: 199 mm (adjustable cushioning)
- Operating pressure: 0.1-0.9 MPa (14.5-130.5 PSI)
- Temperature range: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Port size: PT1/2 (BSPP thread, Rc1/2 optional)
- Mounting: Front flange MA3 (ISO 15552 compatible)
- Body material: Aluminum alloy (anodized surface)
- Seal material: NBR + PU combination seals
- Protection rating: IP67 (dust/water resistant)
- Weight: 5.8 kg (without accessories)
- Dimensions: 340mm(L) × 76mm(W) × 90mm(H) (flange mount height)
High-precision clamping cylinder with integrated mechanical rod lock mechanism, designed for vertical/horizontal position holding in press systems. Features dual anti-rotation guide rods (Ø12mm) and hardened steel pin nose (HRC 50-55). Requires filtered lubricated air (ISO 8573-1 class 4.4.2) with 10-30μm filtration.
- Die clamping in stamping presses
- Workpiece positioning in CNC rotary tables
- Safety interlocks in automated assembly lines
- Tooling fixture locks in welding robots
- Vertical load holding in material stacking systems
Installation note:
Ensure perpendicular alignment (＜0.1mm/m) during mounting. Apply Molykote G-5007 grease
to pin interface quarterly. Maximum side load: 150N at rod end. Requires 3-second minimum
dwell time for secure locking.
| Property | Property Value |
|---|---|
| sku | BAQK50SAAA-199X340 |
| Clamping Arm Position | Clamping Arm and Air Inlet on the Same Side |
| Port Size | PT1/4 |
| Body Mounting Dimensions | Mounting Threaded Hole M10×1.5 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Adjustment Shim | Without adjusting shim |
